As a professional Stainless Steel 316 Shims Manufacturer in India, we provide 316 Stainless Steel Shims in both precision and standard sizes that are trusted for their high strength, tight tolerances, and resistance to corrosion in the strongest abrasive chemical industrial applications, including marine, aerospace, pharmaceutical & heavy engineering industrial sectors. Through ASTM A240 standards we produce hard stainless steel 316 shims that deliver excellent durability with precise dimensions while offering a smooth surface finish.
Stainless Steel 316 Custom Shim Sheet, Jindal 316 SS Shim Sheet, Stainless Steel 316 Shim Plate, 316 SS Shim Sheet Supplier in Mumbai, India
We supply 316 Full-Hard Stainless Steel Shims, which are of superior hardness and strength for high-wear-resistant applications. Our large inventory of 316 stainless steel stock shims allows us to provide your project with an immediate solution. As leading SS 316 shim stockists, we handle shims in various thicknesses, ranging from 0.05mm to 5mm, and can also cut them in custom thicknesses according to the customer's requirements. We are also the largest SS Coil manufacturer in India.
Specification of Stainless Steel 316 Shims
| Item | Stainless Steel 316 shim(Hot rolled, cold rolled) |
| size | 6 "x50", 6"x100" , 12"x50" ,12"x100" 12"x120", and as per Customer Requirement |
| Thickness | 0.001"to 0.039" and as per Customer Requirement |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Surface | the surface and finish of stainless steel 316 shim: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
Gardes of Stainless Steel 316 Shims
Types of Stainless Steel 316 Shims
We provide customized SS 316 shims if you are looking for customized shims. We can supply you with premium grade 316 stainless steel shims in different finishes and sizes at competitive prices.
| Description | HSN Code |
| Stainless Steel Shims | 7312 |
| Stainless Steel Plates/Sheets (for shim stock) | 7219 |
Applications of Stainless Steel 316 Shims
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| 316 | 0.08 max | 2 max | 1.00 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2 - 3 | 11 - 14 | 67.845 min |
| Properties | Metric | Imperial |
| Tensile strength (transverse at room temperature) | 685 MPa | 99400 psi |
| Tensile strength (longitudinal at room temperature) | 696 MPa | 101000 psi |
| Yield strength (transverse at room temperature) | 292 MPa | 42400 psi |
| Yield strength (longitudinal at room temperature) | 316 MPa | 43700 psi |
| Compressive yield strength | 365 MPa | 52900 psi |
| Elastic modulus | 197 GPa | 28573 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (longitudinal at room temperature) | 56% | 56% |
| Elongation at break (transverse at room temperature) | 62.50% | 62.50% |
| Hardness, Rockwell B (transverse at room temperature) | 85 | 85 |
| Hardness, Rockwell B (longitudinal at room temperature) | 85 | 85 |
Sysco Shims is one of the well-known Stainless Steel 316 Shims Manufacturers in India
Sysco Shims
Testing of Stainless Steel 316 Shims
All the products go through a quality check before they are shipped to the customers.
Packing of AStainless Steel 316 Shims
We apply the safest and most efficient means of packaging for every kind of delivery.
Stainless Steel 316 Shims Supplier in India
Sysco Shims is the approved Supplier and Manufacturers of Stainless Steel 316 Shims. With a significant presence in Mumbai and other cities, we continue to hold a dominant position for top SS Shim manufacturers in India.
| Stainless Steel 316 Shims Supplier in Indian Cities | ||||
| Mumbai | Surat | Navi Mumbai | Pune | Gandhinagar |
| Chennai | Belgaum | Vijayawada | Hyderabad | Thrissur |
| Indore | Ranchi | Bangalore | Nashik | Chandigarh |
| Nagpur | Kolkata | Tiruchirappalli | Aurangabad | Kanpur |
Stainless Steel 316 Shims Exporter in India
Sysco Shims is a Exporter and Supplier of Stainless Steel 316 Shims in India supplying hot rolled and cold rolled shims, We set our distribution network with more than 11 countries globally like Qatar, Philippines, Vietnam, UK, Saudi Arabia, South Africa, Kuwait, Singapore, Germany, Oman, United Arab Emirates (UAE), Indonesia, India.
