Sysco Shims is a reliable Stainless Steel 317/317L Foil Manufacturer in India, which manufactures Stainless Steel 317L Polish Foil using high & advanced tech to deliver high accuracy and finish. Our SS 317/317L Foil includes Stainless Steel 317 Hot Rolled Foil and Stainless Steel 317 Galvanized Foil available in customized sizes and lengths, such as cut to size or 100mm - 1500mm width. Every Stainless Steel 317L Cold Rolled Foil goes under strict Chemical & Mechanical Testing, including Tensile & Hardness tests, ensuring reliability. These foils are used widely in various application areas such as chemical processing, marine components, and heat-resistant systems.
Stainless Steel 317L #4 Finish Foil, Stainless Steel 317L Foil, SS 317 Perforated Foil, ASTM A240 Stainless Steel 317L Foil, Stainless Steel 317 Prepainted Foil, DIN 1.4449 Export Quality Foil, Stainless Steel 317 Foil Exporter Supplier in India
Sysco Shims is a prominent Stainless Steel 317/317L Supplier in India, supplying high-quality Stainless Steel 317L #4 Finish Foil manufactured with high-tech & advanced tech for consistent quality. Stainless Steel 317 Prepainted Foil are all manufactured to comply with ISO & International Standards. These ASTM A240 Stainless Steel 317L Foil supplies very good durability and corrosion resistance, which makes them suitable for various areas of application like Chemical Processing Units, Marine Fittings and Industrial Heat-Resistant systems. We are also approved Stainless Steel 321 Foil Manufacturers in India.
Specification of 317 Perforated Stainless Steel Foil
| Standard | ASTM A240, ASME SA240 |
| Thickness | 0.1mm to 12 mm Thk |
| Coil Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc. |
| Coil Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc. |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching. |
| Finish | Hot rolled (HR), Cold rolled (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Galvanized etc. |
Types of Stainless Steel 317/317L Hot Rolled Foil
Applications of Stainless Steel 317 Color Coated Foil
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | 3 – 4 | 11 – 15 | 57.845 min |
| SS 317L | 0.035 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 18 – 20 | 3 – 4 | 11 – 15 | 57.89 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 317/317L | 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| Property | Imperial | Metric |
| Density | 0.285 lbs/in³ | 7.89 g/cm³ |
| Specific Heat | 0.12 BTU/lb-°F (32 – 212°F) | 502 J/kg-°K (0 – 100°C) |
| Modulus of Elasticity | 29.0 x 10⁶ psi | 200 GPa |
| Thermal Conductivity (68°F / 20°C) | 8.1 BTU/(hr·ft·°F) | 14 W/(m·K) |
| Melting Range | 2540 – 2630°F | 1390 – 1440°C |
| Electrical Resistivity | 33.5 Microhm-in at 68°F | 85.1 Microhm-cm at 20°C |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
Sysco Shims is the valuable SS UNS 317L Galvanized Foil Manufacturers in India
Sysco Shims
Testing of Stainless Steel 317 Mirror Finish
All the products go through a quality check before they are shipped to the customers.
Packing of Stainless Steel 317L Chequered Foil
We apply the safest and most efficient means of packaging for every kind of delivery.
Stainless Steel 317/317L Foil Stock Available
| SS 317 Mirror Finish Foil | #8 Finish SS 317L Foil |
| WERKSTOFF NR. 1.4438 Foil | SS 317L 2b finish Hot Rolled Foil |
| UNS S31700 Foil | A240 SS 317 Galvanized Foil |
| Hot Rolled #4 finish SS 317L Foil | SS 317 Hot Rolled Foil |
| Cut to size SS 317L Galvanized Foil | SS 317L Galvanized Foil |
| SS 317 Galvanized Foil | A240 SS 317 Foil |
| WERKSTOFF NR. 1.4449 Galvanized Foil | 2b finish SS 317L Foil |
| SS 317L Cold Rolled Foil | A240 SS 317 Cold Rolled Foil |
| UNS S31703 Cold Rolled Foil | WERKSTOFF NR. 1.4438 Cold Rolled Foil |
| UNS S31700 Galvanized Foil | Stainless Steel 317 Mirror Finish Galvanized Foil |
| WERKSTOFF NR. 1.4438 Hot Rolled Foil | UNS S31703 Hot Rolled Foil |
| A240 SS 317 Hot Rolled Foil | SS 317L Foil |
Stainless Steel 317 HR Foil Supplier in India
Sysco Shims is the approved Supplier and Manufacturers of Stainless Steel 310 Foil. With a significant presence in Mumbai and other cities, we continue to hold a dominant position for top Cold Rolled No.1 Finish Stainless Steel Foil manufacturers in India.
| Stainless Steel 317L Polished Foil Supplier in Indian Cities | ||||
| Mumbai | Surat | Navi Mumbai | Pune | Gandhinagar |
| Chennai | Belgaum | Vijayawada | Hyderabad | Thrissur |
| Indore | Ranchi | Bangalore | Nashik | Chandigarh |
| Nagpur | Kolkata | Tiruchirappalli | Aurangabad | Kanpur |
Galvanized 317L Stainless Steel Foil Exporter in India
Sysco Shims is a Exporter and Supplier of 10 Gauge 317 Stainless Steel Foil in India offering hot rolled and cold rolled Stainless Steel 317 Foil, We set our distribution network with more than 11 countries globally like South Africa, United Arab Emirates (UAE), Oman, UK, Germany, Kuwait, Vietnam, Qatar, Philippines, Indonesia, Singapore, Saudi Arabia (KSA), India.
